Features:
The start button provides smooth flow from Testing to Data saving including OK/NG judgment
Save the test conditions up to 26 patterns. The suitable setting is able to be set instantly
2 test modes are available "BREAK mode" and "KEEP mode"
It can partly measure the test in accordance with standards JIS C2805 and UL 486A-486B
Specifications:
| Model | ACT-1000N | ACT-1000N-V300 |
|---|---|---|
| Capacity | 1000N | |
| Resolution | 1N | |
| Accuracy | +/-0.5% F.S +/-1digit | |
| Unit | N, kgf ,lbf (*1) | |
| Sampling rate | 2000Hz | |
| Safe overload rating | Approx. 150% F.S. | |
| Overload warning | 110% or less | |
| Measuring speed0 | 10/25/50/100 mm/min(Choose from 4 steps) | 25/50/100/300 mm/min(Choose from 4 step) |
| Stroke | Approx.50mm | |
| Allowable sample diameter | Terminal side: Slit width 1~8mm (*2) | |
| Harness side: Aperture width 1~8mm (*2) | ||
| Allowable sample length | 100mm or more | |
| Mode | BREAK/KEEP mode | |
| Number of registered test condition | 26 patterns(A~Z) | |
| Output | USB/RS232C/pass or fail decision signal (OK/NG) | |
| Security lock | Emergency stop button and Overload prevention (at the power on) | |
| Power supply | AC100~240V | |
| Weight | Approx.11kg | |
| Size | W400*D240*H150 | |
| Operating environment | Temperature :0~40 degree Celsius Humidity:20~80%RH | |
| Approved standard | -JIS C2805(2010) "Crimp-type terminal lugs for copper conductors." -UL 486A-486B(2013) " Standard for Safety for Wire Connectors, 9.3.4 Pullout test" |
|
| Accessory | Software, USB cable, Power cord, Inspection Certificate | |
